40L Tank CAD + Pump Case 2025 Build Guide — Bundle
Why this exists
We build our tanks in stainless steel because we value our health and we love to build and develop our own equipment. That way we ensure our equipment perfectly fits our needs. As we pointed out in this article, stainless steel has its drawbacks and at some points, plastics are clearly superior and cheaper. On the other hand, health and repairability and longevity are more important!
Together with the Pump Case we have the complete system for water filtration and storage! In this bundle, you get the Build Guide for the Pump Case 2025 together with the complete CAD package for the 40L Tank for the Front Runner Rack.
What you get
- Build Guide for the Pump Case 2025 — 37 pages of technical documentation
- Native Solid Edge files — fully editable part and assembly files (.par / .asm / .dft)
- STEP file of the assembly — open in Fusion, SolidWorks, FreeCAD, Inventor or any modern CAD system
- Technical drawings as PDF — fully dimensioned, ready to print for the workshop
- DXF files — ready for laser cutting or waterjet, no rework needed
- Weld seam specifications — seam types and placement documented for fabrication
Delivered as a single ZIP. Instant download after purchase.
No physical product — digital download only.
Save 29€ with this Bundle!
119€ incl. VAT — local taxes are included.
What happens next: after purchase you'll receive the download link by email.
Payment is processed by Paddle.com as Merchant of Record. Paddle is the seller of record for this transaction; their terms and refund policy apply.
Who wrote it
I'm Sebastian — mechanical engineer (Dr.-Ing.), and I built this system because I couldn't buy one that told me honestly what it removed. It's been designed, built, and field-tested on our own vehicle, not specified from a catalogue.
The reasoning behind every stage is documented in the guide, and discussed in depth on our blog WeissExplorers.com.
Who this is for
The guide describes the system we built and tested. It does not constitute a warranty of microbiological or chemical drinking water safety in any individual application. Anyone building, modifying, or operating a water treatment system does so on their own responsibility, and is required to verify the suitability of their setup for their own water source and intended use.
Builders who want to have this tank fabricated by a sheet metal shop, or adapt the design to their own vehicle. You'll need a CAD program to open the native files — the DXF and PDF work with any viewer and can go straight into production.
Licence
Single-user license. You may use, modify, and manufacture parts from these files for your own projects, commercial or private. You may not redistribute, resell, or share the files, in original or modified form.
Disclaimer
These files are provided as-is, without warranty of any kind. The design is intended for a vented, non-pressurized water tank. You are responsible for verifying the design for your application, for proper fabrication and welding, and for secure mounting on your vehicle.
Not sure yet?
Check out Builds & Fixes on our blog and read more about the system!
